Thank you for shopping at MaruyamaParts.com and for using the parts lookup system to find parts for your MP4020EH, MP5020EH. You have selected the Carburetor and Fuel Tank diagram for the Maruyama MP4020EH, MP5020EH Water Pumps. Below you will find an interactive part diagram for the MP4020EH, MP5020EH Carburetor and Fuel Tank. If you find the part in the diagram you need you may click on the item number in the diagram or find it in the parts list below the diagram. For the MP4020EH, MP5020EH parts not shown in this diagram you may select from one of the other MP4020EH, MP5020EH part assemblies or select a different Water Pumps altogether. Thanks for shopping with us at MaruyamaParts.com and for making us your source for Maruyama Water Pumps parts.

Position number SKU Product title Price
1 620823 620823 - USE: 626379
$26.99
2 620824 620824 - GOVERNOR ROD
$20.99
3 620825 620825 - GOVERNOR SPRING
$20.99
4 620826 620826 - THROTTLE RETURN SPRI
$14.99
5 627196 627196 - CONTROL ASSY
$103.99
6 620828 620828 - CONTROL LEVER
$37.99
7 998280 998280 - LEVER SPRING
$14.99
8 620829 620829 - CONTROL LEVER WASHER
$16.99
9 990418 990418 - CABLE HOLDER
$13.99
10 998278 998278 - NLA CONTROL LEVER SP
$13.99
11 620830 620830 - CONTROL BASE ASSY
$61.99
12 990419 990419 - CONTROL ADJUSTING SP
$8.99
13 583721 583721 - CABLE RETURN SPRING
$8.99
14 583762 583762 - FLANGE BOLT
$15.99
15 990467 990467 - BOLT
$13.99
16 583723 583723 - NLA GOVERNOR ARM BOL
$12.99
17 583724 583724 - SELF LOCK NUT
$11.99
18 990487 990487 - NUT
$2.99
19 990471 990471 - NUT
$7.99
20 627203 627203 - BOLT
$2.99
21 620831 620831 - PAN SCREW
$2.99
22 620832 620832 - PAN SCREW
$2.99
24 627034 627034 - GASKET SET
$34.99
25 998250 998250 - FLOAT VALVE SET
$45.99
26 583729 583729 - USE: 626364
$56.99
27 583730 583730 - FLOAT CHAMBER SET
$77.99
28 627198 627198 - SCREW SET
$32.99
29 998255 998255 - DRAIN SCREW SET
$21.99
30 583731 583731 - USE: 626367
$30.99
31 583732 583732 - USE: 626368
$53.99
32 627199 627199 - CARBURETOR ASSY
$155.99
33 998258 998258 - THROTTLE STOP SCREW
$29.99
34 627200 627200 - MAIN NOZZLE
$52.99
35 620846 620846 - CHOKE MARK
$6.99
36 620837 620837 - INSULATOR
$32.99
37 583737 583737 - CARBURETOR SPACER CO
$18.99
38 625236 625236 - CARBURETOR PACKING
$5.99
39 620839 620839 - INSULATOR PACKING
$10.99
40 583740 583740 - CHOKE LEVER COMP.
$24.99
41 627201 627201 - COCK LEVER
$18.99
42 998266 998266 - LEVER SETTING PLATE
$2.99
43 998265 998265 - COCK LEVER SPRING
$14.99
44 620840 620840 - FUEL COCK PACKING
$12.99
45 583752 583752 - CLEANER CAP
$24.99
46 620841 620841 - PAN SCREW
$2.99
47 583744 583744 - SPRING PIN
$7.99
48 627202 627202 - MAIN JET
$25.99
49 998260 998260 - PILOT JET SET
$43.99
50 583746 583746 - AIR CLEANER ELEMENT
$31.99
51 583747 583747 - AIR CLEANER GRID
$20.99
52 620843 620843 - AIR CLEANER COVER
$73.99
53 620844 620844 - AIR CLEANER COLLAR
$19.99
54 583750 583750 - AIR CLEANER COLLAR (
$13.99
55 620845 620845 - AIR CLEANER ELBOW AS
$113.99
56 627039 627039 - WIRE HOLDER
$18.99
57 583725 583725 - CIRCLIP
$8.99
58 627040 627040 - PAN SCREW
$2.99
59 626257 626257 - FUEL STRAINER CUP PA
$21.99
60 583742 583742 - FUEL STRAINER CUP
$36.99
